UT-P36 100 MHz 200:1/500:1 Differential Oscilloscope Probe
Prezzo di listino
$459.00 USD
Prezzo scontato
Prezzo di listino
Spedizione calcolata al checkout.
Download
Download
100 MHz differential oscilloscope probe (200:1/500:1 attenuation) for safely measuring floating voltages across motor drives, power converters and bridge circuits.
Compatible with UNI-T oscilloscopes and most oscilloscopes with BNC inputs.
- 100MHz Bandwidth — Captures signal content up to 100MHz for accurate waveform measurement.
- 200:1/500:1 Attenuation — Attenuation ratio suited to the probe measurement range.
- 560VDC+PeackAC / 5600VDC+Peak AC, Accuracy: 2% Maximum Input Voltage — Rated input voltage for safe operation.
- Standard BNC Connection — Compatible with UNI-T oscilloscopes and most oscilloscopes with BNC inputs.
Specifications
| CAT Rating | CAT I 2800 V / CAT II 1400 V |
| Weight | 160 g |
| Storage Temperature | -10 °C - 45 °C |
| Bandwidth | 100 MHz |
| Probe Attenuation | 200:1, 2000:1 |
| Probe Max Voltage | 5600Vpp |
| Rise Time | 3.5ns |
| Cable Length | 30cm input / 90cm output |
| Input Capacitance | 2 pF |
| Input Resistance | 32 MΩ |
| Operating Temperature | 0 °C - 40 °C |
| Noise | ≤ 1.5mVrms (1/200); ≤ 1mVrms (1/2000) |
| Differential Input Voltage | 5600Vpp |
| Common Mode Voltage | 2800Vrms |
| CMRR | ≥ 80 dB DC, ≥ 60 dB 100 Hz, ≥ 50 dB 1 MHz |
